Manufacture |
ABB |
|
Model |
70BK03B-E |
| PN No. |
HESG447270R0001 |
|
Catalog |
Advant OCS with Master SW |
|
Description |
Coupling Module |
| Origin | Sweden |
| HS CODE |
85389099 |
| Dimension |
1.98*0.2*2.61 (CM) |
| Weight | 0.55 kg |
Description:
The 70BK03 module is a component of the PROCONTROL-PS bus system, specifically used in conjunction with the 87TS01/R1239 module. It serves as an interface for data exchange between the PROCONTROL P station and the PROCONTROL-PS protection system. The 70BK03 module is equipped with a standard interface according to RS232 at 19200 baud, which allows it to be connected through serial communication with other modules such as the 87TS01/R1239.
In terms of its physical connection, the front connector X1 or X2 of the 70BK03/R1 module is used for cable connections. This module also uses the same connector X7 as the 87TS01/R1239 module, enabling it to be integrated into the PROCONTROL-PS bus system. Together, these two modules form a robust data transfer infrastructure within the PROCONTROL P system.
