Description:

Features
1. Voltage and current measurement via conventional measuring transformers or current sensors and voltage dividers.
2. Fixed man-machine interface including a large graphic display, or an external display module for flexible swichgear installation.
3.Extended functionality including protection, control, measurement, condition monitoring and communication.
4. Non-directional/directional overcurrent/earth-fault protection functions, over- /undervoltage protection functions and special functions for the protection of motors and generators, e.g. voltage controlled overcurrent protection, differential protection with several principles, underexcitation protection, underimpedance protection (line back-up prot.), thermal overload protection, protection against unbalanced load, abnormal frequency protection, reverse or low-forward power protection and start-up supervision for motors.
5. Control functions including local and remote control of switching objects with synchro-check, status indication of the switching objects and interlockings on bay and station level.
6. Measurement of phase currents, phase-tophase and phase-to-neutral voltages, neutral current and residual voltage, frequency, power factor, active and reactive power and energy.
7.Optional RTD/mA I/O-module for stator winding, bearing and ambient temperature monitoring. Analog mA outputs for interfacing with process control system.
8. Condition monitoring including circuitbreaker condition monitoring, trip circuit supervision and internal self-supervision of the machine terminal.

sheet Link:

ABB MIM6030 1MRS050471 TRANSFORMER MODULE PDF Datasheet
