ABB TU831V1 3BSE013235R1 Extended Module Termination Unit

ABB TU831V1 Extended Module Termination Unit  in stock.

  • Item NO.:

    TU831V1

  • Payment:

    T/T

  • Product Origin:

    SWEDEN

  • Color:

    Depends on material

  • Shipping Port:

    Xiamen

  • Lead Time:

    5-7 days

  • Goods Stock:

    99

  • Product weight:

    0.22 kg
Inquiry now


Manufacture
 ABB
Model
 TU831V1
PN No. TU831V1
Catalog
 800xA
Description
 Extended Module Termination Unit
Origin U.S.A.
HS CODE 85389091
Dimension 6.4*12.05*11 (CM)
Weight 0.22 kg

Description:

The TU831/TU831V1 is an 8channel extended termination unit MTU) designed forthe AB8 s800 10 system. This MTU is a pasive unit that conects field wiring to lomodules,distributing the ModuleBus and generating adresses for the 0 modules. t supports up to 250 V rated votage and 3 A maximum current per channel, providing arobust connection for industrial applications.
Features:

  • Advanced Technology
The TU83lVl incorporates state-of-the-arttechnology for superior performance.
  • Up to 8 lsolated Channels
lt can handle up to 8 isolated channels of fieldsignals.
  • Connections
Provides connections to ModuleBus and l/0 modules.
  • Mechanical Keying
Prevents insertion of the wrong l/0 module.
  • DIN Rail Mounting
Can be mounted on a standard DlN rail.
  • Latching Device
Secures the MTU to the DlN rail for grounding.

Specifications:
Model: TU831/TU831V1
Rated Maximum Continuous Current per Channel: 3 A

  • ModuleBus Current Distribution
-5 V: 1.5 A
-24 V: 1.5 A
  • Wire Size Compatibility
-Solid: 0.2 – 6 mm²
-Stranded: 0.2 – 4 mm², 24 – 10 AWG
Torque Range: 0.5 – 0.6 Nm
Stripping Length: 7 mm
Operating Temperature: -40'C to 70°C
Input Voltage: 24 VDC
Mechanical Keys: 36 configurations
I/O Module Lock: Yes, locks module in position
Protection: IP20 (IEC 60529)
Insulation Voltage: 250 V
Dielectric Test Voltage: 2000 V AC
Frequently Asked Questions:
1.What is the maximum current per I/O channel?
A: The maximum current per I/O channel is 3 A.
2. How many channels does the TU831/TU831V1 support?
A: The MTU supports up to 8 isolated I/O channels.
3: What is the protection rating of the TU831/TU831V1?
A: It has an IP20 protection rating according to IEC 60529.

Datasheet Link:

ABB TU831V1 Extended Module Termination Unit  PDF Datasheet
