CC-PUIO31 Honeywell 51454220-176 Universal Input Output

Description:

 The UIO (CC-PUIO31) module is introduced with R432 and has 32 configurable input or output channels that are identical to the UIO (CC-PUIO01) module

The Series C UHIO is comprised of the following Series C components.
• 9-port Control Firewall CC-PCF901
• C300 Controller CC-PCNT02
• Universal Input/Output (UIO) Module CC-PUIO01 or CC_PUIO31

In addition to the existing Series C components, the UHIO contains additional components listed in the topic as listed below in Table 85. All of these components are packaged together in various UHIO Configurations. These configurations are defined within the section titled “Components of UHIO” on page 249.

The following table lists the model number of UHIO components.

The horizontal UHIO IOTA is designed for UIO and the dimension of the IOTA is same as that of horizontal C300/CF9 IOTA. This IOTA enables you to place the redundant UIO module side-by-side or horizontally. The placement of a UIO module differs from the placement of a Series C module, wherein you can only place the Series C modules vertically and hence it is named as "Universal Horizontal I/O." The horizontal UHIO IOTA is designed to interface the Series C UIO module with the CB/EC terminal panel – the TCBxx.

The following figures display the engineering drawings of the UHIO IOTA and the UHIO-2 IOTA.

Figure

Details:
·Two processors running synchronously
·Flash memory for system and application program
·Flash memory for backup of system and application program
·RAM with battery backup (battery located in BKM-0001)
·A redundant communication link with the other Control Processor
·RAM for the redundant communication link data
·Data comparators for the processors and their memory
·Data exchange with its communication modules
·Minimum and maximum execution time monitor
Frequently Asked Questions:
1.What is the replacement model for CC-PUIO31?
    FC-USI-0003
2. What is the IP rating?
    IP65 (dustproof and waterproof) is common.
3. How do I interpret fault codes or LED indicators?
     A solid/flashing red light may indicate a power failure or sensor malfunction.
     Refer to the fault code table in the manual for troubleshooting.

Datasheet Link:

CC-PUIO31 Honeywell 51454220-176 Universal Input Output PDF Datasheet
