Manufacture |
GE |
|
Model |
IS215UCCCH4A |
| PN No. |
IS215UCCCH4A |
|
Catalog |
MKVIe |
|
Description |
CPCI Controller Card |
| Origin |
United States (US) |
| HS CODE |
85389091 |
| Dimension |
38*28*6 (CM) |
| Weight | 1.0 kg |
Description:
GE IS215UCCCH4A MARK VIE CPCI CONTROLLER CARD
Part Number: IS215UCCCH4A
Manufacturer: General Electric
Series: Mark VIe
Product Type: Controller Card
Microprocessor: Intel Pentium M Processor 1.6 GHz
Memory: 256 MB
Operating System: QNX Neutrino
Availability: In Stock
Country of Origin: USA
Manual: GEH-6721G
The IS215UCCCH4A is a VME controller board manufactured by General Electric as part of the Mark VIe family for gas turbine control systems.
It is a modular assembly consisting of the IS200 EPMC daughter board, IS215UCCC H4. 128 MB of flash memory, and 256 MB of DRAM.
Sometimes referred to as the 3U Compact PCI, there are six Ethernet-style ports on the panel. The labeling indicates the intended function of each port.
In addition, the panel has a number of LEDs. the controller detects certain system errors during startup, download, and normal operation.
Diagnostic alerts can be displayed and reset from the ToolboxST application and logged as history on WorkstationST.
sheet Link:
GE IS215UCCCH4A MARK VIE CPCI CONTROLLER CARD PDF Datasheet
