The central module of the PES H41q-HR contains the essential functions demonstrated in the structure of the central module:
– Microprocessor
– Flash-EPROMs of the program memory for the operating system and the user's program usable for min. 100.000 writing cycles
– Data memory in sRAM
The enclosure of the controller is made of V2A stainless steel. The controller is intend for mounting on a mounting plate. The enclosure is equipped with a massive aluminum plate, see Figure 8. Figure 9 specifies the centre hole distances.
