IS200STAOH2A GE MKVIe, Analog Out Terminal Board, Simple

The Mark Vle Control Analog Output Module, Cat. No. IS220PAOCH1B is intended to be used with accessory terminal board Cat. Nos. IS200STAOH1A, IS200STAOH2A, IS200TBAOH1C

Item NO.:
IS200STAOH2A
Payment:
T/T
Market Price:
$2500
Product Origin:
U.S.A.
Shipping Port:
Xiamen
Lead Time:
5-7 days
Goods Stock:
9
Product weight:
1.2 kg

Inquiry now

product introduction

Manufacture	GE
Model	IS200STAOH2A
PN No.	IS200STAOH2A
Catalog	MKVIe
Description	Analog Out Terminal Board, Simple
Origin	U.S.A.
HS CODE	85389091
Dimension	38185 (CM)
Weight	1.2 kg

Description:

PAOC Analog Output Module
The following I/O pack and terminal board combinations are approved for use in hazardous locations:
• Analog output pack IS220PAOCH1B
with terminal boards (accessories) IS200STAOH1A, IS200STAOH2A, or IS200TBAOH1C

IS200STAOH2A is a Simplex Analog Output Terminal Board manufactured and designed by General Electric as part of the Mark VIe Series used in Distributed Control Systems. Compact analog output terminal boards are available, such as the Simplex Analog Output (STAO) terminal board, which is made for flat or DIN-rail mounting. Eight 0-20 mA analog outputs on STAO are powered by the PAOC I/O pack. Similar to the TBAO terminal board, the onboard circuitry and noise reduction are present. The board is equipped with high-density Euro-block style terminal blocks for connecting to the customers' devices. The board is identified to the I/O processor by an onboard ID chip for system diagnostics. The D-type connector is used to connect the I/O pack, which uses Ethernet to talk to the controller.

INSTALLATION:

The STAO and a plastic insulator are mounted in a panel or on a DIN-rail-mounted sheet metal carrier. The STAO plus insulator mount can also be attached to a sheet metal assembly that is bolted directly to a cabinet. Driven equipment can be placed up to 300 meters (984 feet) away from the turbine control cabinet and shouldn't have a resistance greater than 900. There are two varieties of Euro-block terminal blocks:

An unpluggable mount terminal block with 36 terminals is present on STAOH1.
A permanently installed terminal block with 36 terminals is present on STAOH2.

As seen in the following diagram, the eight analog outputs are attached directly to the terminal block. For the SCOM connection, there are two screws. Typically, shielded twisted pair (#18 AWG) wires are utilized. An external mounting bracket supplied by GE or the client is used by the I/O cable shield termination. The mounting holes E1 and E2 are for the chassis ground screw connection (SCOM). To save cabinet space, DIN-type terminal boards can be stacked vertically on the DIN rail.
