PHARPSCH100000 ABB Power Supply Chassis

Description:
The ABB PHARPSCH100000 power chassis provides mounting slots for two redundant power supply trays, cooling fans, power output terminals, a DIN rail for the DC bus monitoring assembly, and a status output terminal connection.

Cables connect the power terminals for 5 VDC, ±15 VDC, -15 VDC, and 24 VDC to the power bus bar for distribution to the cabinet.

The 48 VDC and 125 VDC terminals are for field I/O devices.

Power supply trays can be removed from the power chassis and replaced while the system is online.

Prior to removing a power supply tray, power to that power supply tray must be switched off at the PEP.
Parameters:
Product ID:   PHARPSCH100000
Power Input:  Typically 120/240VAC, meeting industry standard voltage requirements.
Power Output:            5V @ 60A
                                 +15V @ 3A
                                  -15V @ 3A
                                   24V @ 17A
                                  125V @ 2A
Power Rating:  Depending on the output configuration, the total power can reach over 800W.
Cooling System:  Equipped with a system monitoring and cooling fan (PHARPSFAN03000) to ensure efficient heat dissipation during high-load operation.
Mounting Options:  Supports single-chassis and dual-chassis installations to accommodate industrial control systems of varying sizes.
Features:

• High Reliability

As one of ABB's core products, the PHARPSCH100000 utilizes high-quality power modules and a robust heat dissipation design, ensuring long-term, stable operation in harsh industrial environments.

• Multiple Outputs

Providing a variety of voltage and current combinations to meet the power supply needs of various industrial modules.

• Modular Design

Supports flexible module expansion, allowing users to add or replace power modules based on actual needs, improving system maintainability and scalability.

• Strong Compatibility

Highly compatible with other ABB industrial automation products, facilitating integration into existing automation control systems.
Frequently Asked Questions:
1.What's payment term can support?
T/T Only

2.When does the warranty period start?
One year from the time the client receives the goods.

Datasheet Link:

PHARPSCH100000 ABB Power Supply Chassis PDF Datasheet
