Manufacture |
ABB |
|
Model |
PM510V16 |
| PN No. |
3BSE008358R1 |
| Catalog | AC460 |
| Description |
Processor Module |
| Origin | Sweden/Malta/India |
| HS CODE |
85389091 |
| Dimension |
47*28*3 (CM) |
| Weight | 0.9 kg |
Description:
The PM510 Processor Module provides sufficient RAM for most applications. Up to 11 MByte is available for application programming. Memory is generally not a limiting factor when sizing the system; however, it is advisable to do a memory calculation to verify that your application does not exceed the memory capacity. Use the following Table 3-5to estimate the memory usage requirements.
How to Reduce Processor Module load
Analyze the application to determine where you can reduce the Processor Module load most effectively. Areas of concern when reducing the Processor Module load are:
• A slower base rate
• Slow down scan rates on CCF loops
• Phase of loops
• Slow down TLL scan rate.
Basic Unit
The minimum configuration for the Advant Controller 460 is provided by the basic unit which
consist of:
Description
Qty
RF522
Subrack and Backplane
1
SR511
Primary Power Regulator
2
TC520
Monitor
1
SC540
DCN Communications Submodule
2
CS512
DCN Interface Module
2
RA102
ESD Board and equipment
1
TK451
Cable, 24V - Rack
1
TK456V021
Cable, 24V - Fan
1
TK458
Cable, Fan - TC520
1
RC510
Fan
1
Frequently Asked Questions:
1.What's the tipical voltage and max voltage for PM511?
5 V d.c. 5.0 A
24 V d.c. 1.49 A
2.What is the payment term?
Wire transfer only.
3.When does the warranty period start?
One year from the time the client receives the goods.
Datasheet Link:
PM510V16 ABB 3BSE008358R1 Processor Module 16 MByte PDF Datasheet
