SDV541-S53 S2 Yokogawa Digital Input Module

Description:

Single Module
The calculation formula is different between channels 1 to 8 and channels 9 to 16 of the SDV541 module; possible
cable lengths in channels 9 to 16 are shorter than those in channels 1 to 8.

FEATURES
• High performance and low power consumption modular controller
• Memory with ECC.
• FCN-RTU can be used wide temperature range and high altitude place.
• Analog and digital I/Os adequate for gas/oil wellhead control built in CPU module
• Four serial ports for plural communications built in CPU module
• Up to eight additional I/O modules (with NFBU200)
• Wide voltage range (10 to 30 VDC input) power supply module (NFPW426)
• Power supply module can be duplexed (NFBU200 with NFPW444)
• Low heat dissipation eliminates the need for a fan
• A wealth of RAS features — CPU self-diagnostics, temperature monitoring, I/O diagnostics, and more
• Additional I/O modules (except CPU embedded I/Os) hot-swappable

Specifications:
Model SDV541

Number of inputs 16-channel, module isolation (*3)
Input signal
No-voltage contact
ON: 1 kΩ maximum
OFF: 100 kΩ minimum
Input current 6 mA ± 20 %
(External power supply, 24 V DC at 0 Ω input)
Contact rating 24 V DC +20 % / -10 % (*4), 10 mA or greater
External power supply 24 V DC +20 % / -10 % (*3) (*4)
Current capacity: 200 mA
Instantaneous maximum permissible
input voltage 30.0 V DC
Input response time 40 ms maximum
Withstand voltage (*1) (*2) 2 kV AC between input signal and system for 1 minute, 16-input line collectively
connected (*5)
Current consumption 290 mA maximum (5 V DC)
140 mA maximum (24 V DC)
Weight Approx.

0.36 kg (For pressure clamp terminal block or MIL cable)
Approx. 0.41 kg (With signal cable interface adapter)
External connection
Pressure clamp terminal
MIL cable
Dedicated signal cable (AKB331)
