140DDM39000 Schneider Electric Modicon Quantum Discrete Input Module

140DDM39000 Schneider Electric Modicon Quantum Discrete Input Module in stock.

Item NO.:
140DDM39000
Payment:
T/T
Market Price:
$140
Product Origin:
France
Color:
Depends on material
Shipping Port:
Xiamen
Lead Time:
5-7 days
Goods Stock:
99
Product weight:
0.91 kg

Inquiry now

product introduction

Manufacture	Schneider
Model	140DDM39000
PN No.	140DDM39000
Catalog	Modicon Quantum
Description	Ethernet network TCP/IP module
Origin	U.S.A.
HS CODE	85389081
Dimension	516.531.5(CM)
Weight	0.91kg

Description:

The Schneider Electric 140-DDM-390-00 Mixed Discrete I/O Module is a versatile industrial automation component designed to manage both input and output signals with exceptional reliability. Built to integrate seamlessly into Schneider Electric’s Modicon Quantum system, it is ideal for applications that require precise control over multiple discrete I/O points in a single device. Backed by a two-year MRO Electric and Supply warranty, the 140-DDM-390-00 delivers long-term durability and performance in demanding industrial environments, making it a cost-effective and efficient solution for managing automation processes.

Specifications:
Product Name: 140DDM39000

Input Voltage: 24V DC
Communication Interface: Modbus, TCP/IP
Ethernet Input Count: 16 times
Output Count: 16

Operating Temperature: -20°C to 60°C
Network Frequency Limits: 47…63 Hz
Maximum Leakage Current: 1.9 mA
Storage Ambient Temperature: -40…85 °C
Relative Humidity: 95% (Non-condensing)
Input Current: 11.1 mA/ 13.2 mA
Input Impedance: 2600 Ohm/ 3100 Ohm
Network Frequency Limits: 47/63 Hz
Bus Current Requirement: 250 mA
Max. Power Dissipation: 10.9 W
Isolation Between Groups: 1780 Vrms
Max Leakage Current: 1.9 mA
Addressing Requirements: 2 input words
Response Time: 4.9 to 0.75 ms

Feartures:

-High-speed processing, fast response time

-Built-in diagnostics and fault detection

-User-friendly programming interface

-Rugged and durable, suitable for industrial environments

-Flexible connectivity options for seamless integration into existing systems

Frequently Asked Questions:
1.What type of inputs and outputs does the 140-DDM-390-00 module support?
The module supports 16 discrete inputs with sink logic, divided into two groups of 8, and 8 discrete outputs organized in two groups of 4, also using sink logic.

2.What is the maximum voltage the inputs can handle?
The inputs operate within a 24 V DC range but can handle voltage up to 56 V for brief 1.3 ms pulses, making them resilient to short-term surges.

3.How much load current can each output handle?
Each output point can manage up to 0.5 A, each output group up to 2 A, and the entire module up to 4 A. This load flexibility is ideal for diverse industrial applications.

4.What protections are included in the module?
The module has a 5 A fuse for each output group, transient voltage suppression, and resistor-limited input protection, ensuring robust protection against overcurrent and voltage spikes.
