18745-03 Bently Nevada, 7200 XL Proximitor

Description:

7200 Proximity Transducer Systems 5 mm and 8 mm
Proximitor: 18745-口口
03 For combined probe and extensioncable system length of 5 metres(16.4 feet).
04 For combined probe and extensioncable system length of 9 metres(29.6 feet).

1.Unthreaded length must be at least 0.8 inches (20 mm ) less than case length.

2.Exension cable physical lengih equals the electrical length, ±10%.

3.For use with the 18745-03 five-metre Proxirnitor only

SPECIFICATIONS:
Part Number: 18745-03
Manufacturer: Bently Nevada
Product Type: 7200 XL 5/8mm Proximity Sensor Module
Transducer Power Supply: 24 Vdc
VoltageCompliance: 0 to +12 Vdc
Input signal range: +10.0 V to -24.0 V
OperatingTemperature: -45 ºC to +65 ºC
Number of channels: 12
Range:(0 to 50 to 0.20 in)MM
Accuracy:+0.5% full scale
Nonlinearity:+1%full scale
Resolution:0.1pm(0.000004 in)
Frequency Response:0to 10 kHz0perating
0utput:4-20 mA DC
Power Supply:24 VDC +10%

Enclosure Rating:IP67

Features :

• Non-Contact Measurement

Eliminates wear and tear on the target surface, ensuring a long servicelife.

• High Accuracy

Measures displacement with +0 5% ful1-scale accuracy, ensuring precise results.

• Wide Temperature Range

0perates from -40°c to +200°c(-40'F to +392°F),suitable for various environments.
High Signal-to-Noise Ratio: Provides reliable measurements even in noisy environments

• Reverse Polarity Protection

Safeguards the sensor from damage in case of accidental power supplyreversal.

Frequently Asked Questions:

1.How long is Connecting cable?
5 meters

2.What is operating temperature of 18745-03?
Proximitor:-60 °F to +212 °F (-51°C to +100°C).

3.When does the warranty period start?
One year from the time the client receives the goods.

Datasheet Link:

18745-03 Bently Nevada, 7200 XL Proximitor PDF Datasheet
