3BUS208946-001 ABB CSS Power Supply Module

Description:

3BUS209375-001 is obsoleted in December 2013; 3BUS209375-022 is its replacement part. In many situations a software update is required to use this part. See 3BUS209544 - Network Platform Software Reference Manual or Field Alert 3BUS209375-800 for further information.

** Please check hardware ID label for exact model details.
*** 3BUS215432-001 is a new power supply kit introduced December 2013. It is a direct replacement for the original power supply and any of its modules. To repair a failed power supply or module, replace the complete power supply. See section DC Power Supply Replacement on page 10-19. The original and now obsolete modular power supply is shown in Figure 10-24 on page 10-25.

**** New type power supply without its special connecting cable. See section DC Power Supply Replacement on page 10-19. Use when this power supply type already exists.

Pharameters:

Permissible temperature range during operation         0...55 °C
Rated supply voltage         24 V DC
Nominal signal voltage at inputs         V DC
Max. current consumption         0.15 A
Max. nominal load capacity for supply terminals         4.0 A
Max. power dissipation inside the unit         10 W
Protection against incorrect polarity of supply voltage         yes
power supply         max. 2.5 mm2
CS31 system bus         max. 2.5 mm2
signal terminals         max. 1.5 mm2
reference potentials ZP0, ZP1, ZP2, ZP3         max. 1.5 mm2
Number of inputs         32
Number of interfaces         1 CS31 system bus interface
Address setting         Coding switch under the cover located on the right side of the housing
Operation and error displays         a total of 33 LEDs
