83SR07 ABB GJR2392700R1210 Control Module

Description:

The 83SR07 ABB GJR2392700R1210 module is used for stored-program analog control of oneor two process variables. The module is provided with twocontinuous outputs for output of the correcting variables. Thefollowing types of actuators can be controlled:
-electrohydraulic actuators
-electropneumatic actuators
-electric-motor-powered drives
The drives are positioned either locally at the transducer or incase of electric-motor-powered actuators, in a continuouslyoperating power electronics system.lt is also possible tosupplement the single variable analog controls by a higher.level master control system.
The module is intended for use in connection with the process operator station.
The module incorporates the function blocks for implementingcontinuous single variable controllers. Additional functionblocks are available for siqnal conditioning.
In the analog control mode, the module is used with fixedcycle times. This is 100 ms for one actuator and 200 ms fortwo actuators.
The cycle time is specified by means of function block KONwhich is the first block to appear in the structure.The module incorporates two hardware process interfaces forthe power controller units and the process.
