Manufacture |
ABB |
|
Model |
89NG08 |
| PN No. |
GKWN000297R1000 |
|
Catalog |
Advant OCS with Master SW |
|
Description |
Power Supply Module |
| Origin | Germany |
| HS CODE |
85389099 |
| Dimension |
1.98*0.2*2.61 (CM) |
| Weight | 0.55 kg |
Description:
ABB 89NG08R1000 GKWN000297R1000 Power Supply Module
The station-bus cabinet receives a redundant 24 V D.C. supply from two separate power supply systems. Power supply module 89NG08 is responsible for supply voltage monitoring, voltage limitation, circuit formation, and power distribution. For selective cabinet connection and disconnection, 2 highcapacity m.c.b.s are provided. As protective devices, they merely fulfill a back-up function and can respond selectively with respect to the external cabinet fuses.
The power supply module is prepared for a maximum of one plus three 24 V/5 V 89NG03 power supply modules. Sub-rack“G” is wired for a 89NG03 power supply module, a central 5 V supply. Sub-rack “K” can subsequently be equipped with an additional power supply module. Sub-rack G can be rewired for the decentralized 2 x 24 V D.C. supply. The redundant 24 V D.C. power supplies are kept separate and non-interfering up to each individual electronic module and up to the fusing of the 89NG03 power supply module.
What makes P14 stand out:
1.Modular Design: Offers scalability for any size plant, from basic control tasks to large-scale operations.
2.Standardized System: Uses a uniform approach for all control functions, simplifying operation.
3.User-Friendly Interface: Straightforward structure and functionalities make it easy to operate.
4.Data Accessibility: Ensures easy access to all critical plant data for informed decision-making.
5.Future-Proof Technology: ABB's "Evolution without Obsolescence" policy guarantees compatibility with upgrades, protecting your investment.
sheet Link:
ABB 89NG08R1000 GKWN000297R1000 Power Supply Module PDF Datasheet
