CC-PCNT02 Honeywell CC-PCNT02 Supported C300 Models

Description:

Honeywell’s C300 Controller provides powerful and robust control for the distributed control system (DCS). The C300 is a node in operating Honeywell’s field-proven deterministic Control Execution Environment (CEE) core software. The CEE software provides a superior control execution and scheduling environment. Control strategies for each controller node are configured and loaded through a common Control Builder, an easy and intuitive engineering tool.

In addition to a standard and robust library of pre-built function blocks and algorithms, the C300 Controller also supports Custom Algorithm Blocks (CABs). Custom Algorithm Blocks are similar in purpose and structure to the standard function blocks that are distributed with Control Builder. However, CABs have user-defined algorithms and data structures, allowing custom tailored strategies to be developed to specific requirements.

The C300 controller shares its hardware design with the Series 8 I/O, offering an innovative design that reduces footprint and installation and maintenance costs. The C300 controller module is mounted on the C300 Input Output Termination Assembly (IOTA). The C300 IOTA contains only passive devices such as FTE address switches. Figure 1 below depicts the IOTA components.

This upgrade kit contains installation instructions to upgrade from C300 PCNT01 to PCNT02 (with extended memory). The C300 Controller CC-PCNT02 is a fully-compatible replacement for C300 CCPCNT01. Upgrade Kit configuration.

Details:
·Two processors running synchronously
·Flash memory for system and application program
·Flash memory for backup of system and application program
·RAM with battery backup (battery located in BKM-0001)
·A redundant communication link with the other Control Processor
·RAM for the redundant communication link data
·Data comparators for the processors and their memory
·Data exchange with its communication modules
·Minimum and maximum execution time monitor
·Memory error handler
·1oo2D functionality
·24V and 5V monitoring
·Emergency Shut Down Input (24V)
·Two outputs (for non-redundant resp. redundant IO)
Frequently Asked Questions:
1.What is the replacement model for CC-PCNT02?
    FC-USI-0003
2. What is the IP rating?
    IP65 (dustproof and waterproof) is common.
3. How do I interpret fault codes or LED indicators?
     A solid/flashing red light may indicate a power failure or sensor malfunction.
     Refer to the fault code table in the manual for troubleshooting.

Datasheet Link:

CC-PCNT02 Honeywell CC-PCNT02 Supported C300 Models PDF Datasheet
