CE110 110-100-CT-VO Vibration Acceleration sensor

Description:

Standard Sensitivity 100 mV/g ±5% (Nominal at 80 Hz)
Frequency Response 2 Hz to 10 kHz ±5% (-3 dB at 0.8 Hz)
Mounted Base Resonance 18 kHz (nominal)
Isolation Base isolated
Dynamic Range ±80g
Transverse Sensitivity Less than 5%
Electrical Noise 0.1 mg max
Current Range 0.5 mA to 8 mA
Temperature Range -55°C to +140 ºC
Bias Voltage 12 Volts DC (nominal)
Case Material Stainless steel
Mounting Torque 8 Nm
Weight 110 g (nominal)
Sealing IP67
Maximum cable length 1000 meters
Standard cable length 5 meters for AT and EX versions, cable diameter 4mm
Mounting connector 2 pin MS for CT versions
ATEX version Intrinsic safe accelerometer ATEX Group I & II
Approved
Barrier MTL 728- BAS01ATEX7202, P&F Z728-
BAS01ATEX7005 or any other Barrier that conforms
to note 4 of ATX011
