Manufacture |
ABB |
|
Model |
DP640 |
| PN No. |
3BHT300057R0001 |
|
Catalog |
S600 |
|
Description |
Rotational Speed Meter Module |
| Origin | Sweden |
| HS CODE |
85389091 |
| Dimension |
27*4*25(CM) |
| Weight | 1.33 kg |
Description:
S600 I/O speed meter input, max 50 kHz, ±13 mA, 24 V d.c. or 5 V d.c., detection of direction through second speed meter input, overspeeed trip logic with trip signal output via solid state 24 V d.c. and dry contact 60 V d.c., speed meter inputs and solid state output are individually opto-isolated.
Note! This part is exempted from the scope of 2011/65/EU (RoHS) as provided in Article 2(4)(c), (e), (f) and (j) therein
(ref.: 3BSE088609 – EU DECLARATION OF CONFORMITY
- ABB Advant Master Process Control System)
Features and benefits
- Input Current / Voltage: ±13 mA; 24 V DC or 5 V DC
- Key Functions: Direction detection using a secondary speed input and built-in overspeed trip logic.
- Outputs: Solid-state (24 V DC) and dry contact (60 V DC) trip signal outputs.
- Isolation: Individually opto-isolated speed inputs and solid-state outputs.
Frequently Asked Questions:
1.Does the customer arrange for the inspection before the goods are shipped?
Confirmed acceppted this issue
2.What is the payment term?
Only wire transfer
3.When does the warranty period start?
One year from the time the client receives the goods.
Datasheet Link:
DP640 ABB 3BHT300057R0001 Rotational Speed Meter Module PDF Datasheet
