DS200TCPDG2BEC GE Mark V POWER DISTRIBUTION BOARD

Description:
The GE DS200TCPDG2BEC is a high-reliability Power Distribution Module designed for the Mark V Speedtronic turbine control system. It distributes 125 VDC power to all control cores, including I/O cores, Control Engine cores, and TCEA boards, while supplying 120/240 VAC power to ignition transformers.

Operators can safely isolate individual cores using onboard toggle switches, which simplifies maintenance and enhances operational safety. Moreover, the module powers DTBC and DTBD terminal boards, with output continuously monitored by the CTBA terminal board, ensuring reliable turbine control and ignition functionality.
Parameters:

Product Name: DS200TCPDG2BEC
Function: Powers all control cores
Power Output: 125VDC
Fuses: 36 in total; green LED indicates operating status, red LED indicates blown status
Toggle Switches: 8 toggle switches for configuration and master control
Signal Line Characteristics: 4 terminals for signal path input/output
Connectors: 10-pin connectors for system integration
PCB Protection: Standard PCB overlay
Memory: Onboard RAM
Mounting Method: Panel mount within a Mark V rack
Frequently Asked Questions:
1.What is Ds200TCPDG2B?
The DS200TCPDG2B is a power distribution circuit board developed by GE
2.How much power is delivered to the cores?
All of the cores receive 125 VDC power.
3.Can individual cores be powered down safely?
Yes, onboard toggle switches allow safe isolation of individual cores.
4.Does it support monitoring for fault detection?
Yes, the CTBA terminal board continuously monitors the power distribution output.
