IS420UCSCH2A-G-V0.1-A GE MARK VIe UCSE Module

Description:

IS420UCSCH2A is 1.6 Ghz 1600MHz Dual Core AMD G Series CPU Module

GE Vernova’s Mark VIe control system is an integrated control system that is widely used in a diverse range of applications including gas and steam turbines, safety systems, wind turbines, gasification, hydro, nuclear, and combined cycle power plants. These diverse applications require a controller that can deliver the high performance and flexibility needed to run application specific control reliably.

The Mark VIe UCSE is a stand-alone controller that uses QNX® Neutrino, a real-time, multi-tasking operating system (OS), to run application-specific control system logic.

The UCSE controller offers the following advantages:
• Single module
• No battery
• No jumper settings required
• ToolboxST programmatically updates the host application board programmable devices

The UCSE controller mounts in a panel and communicates with I/O modules through on-board I/O network (IONet), PROFINET, High-speed Serial Link (HSSL), and/or other interfaces.

The available versions of the UCSE controller are: UCSEH2A for Mark VIe, UCSEH2B for Mark VIe, LS2100e Static Starters, and EX2100e Voltage Regulators, and UCSEH2C for EX2100e Static Exciters.

Reliable, High-Speed Performance
The UCSE Mark VIe controller is designed for high-speed, high-reliability industrial applications. It is loaded with software specific to its application. As a turbine or balance of plant (BoP) controller, it runs the Mark VIe firmware and blockware applications and utilizes Mark VIe IONet interfaces. IONet is a private special-purpose Ethernet that only supports Mark controls I/O packs and controllers. IEEE 1588 protocol is used through the IONet interfaces to synchronize the clock of the I/O modules and controllers to within ±100 microseconds. External data is transferred to and from the IO Packs the controller over the IONet Ethernet interfaces. This includes process inputs/outputs to the I/O modules. Unlike traditional controllers where I/O is on a backplane, the UCSE controller does not host any application I/O. In a redundant set, all I/O networks are attached to each controller, providing them with all input data. This hardware and software architecture guarantees that no single point of application input is lost if a controller is powered down for maintenance or repair.

Application Specific Control
Outcome Optimizing Controls offer advanced capabilities that simplify system architecture and dramatically reduce applied engineering costs.

MarkVIe UCSE’s flexible design allows for it to be used not only for turbine control applications, but also for DCS applications, especially in steam and gas power plants.

The native PROFINET capability on the UCSEH2A provides productivity and performance advantages necessary for DCS and BoP control applications for power generation.

Frequently Asked Questions:

1.What is the IS215VCMIH2CC?
It is the MKVI Bus Master Controller Card by General Electric (GE).
2.What is the Processor of the IS215VCMIH2CC model?
Texas Instruments TMS320C32 32-bit digital signal processor
3.How To install the VME Board IS215VCMIH2CC?
Directly plug one VME board for simplex or three PAIC I/O packs for TMR into the terminal board connectors

Datasheet Link:

IS420UCSCH2A-G-V0.1-A GE MARK VIe UCSE Module PDF Datasheet
