Manufacture |
EPRO |
|
Model |
MMS6410 |
| PN No. | MMS6410 |
|
Catalog |
MMS6000 |
|
Description |
Dual Channel Measuring Amplifier |
| Origin | Germany |
| HS CODE |
85389099 |
|
Dimension |
12*16*3 (CM) |
|
Weight |
0.5 kg |
Description:
The MMS 6410 dual channel measuring amplifier measures shaft displacements with the help of inductive transducers in half- or full bridge configuration or with the help of differential transformers. Each measuring channel may operate separately or calculate sum or difference values of the measuring results of both channels.
The MMS 6410 measuring amplifier permits measurement of static as well as of dynamic signals such as displacements, angles, forces, torsions or any other physical quantities, that can be measured with inductive transducers. Measurements of displacements serve the construction of turbine protection systems. They provide signals for analysis and diagnosis systems to be further processed in field bus systems and networks.
Such cards of the MMS 6000 family are suitable to build up systems for increasing performance, efficiency and
safety of operation and to extend the machines' life times. Application fields of the epro measuring amplifiers are steam, gas and water turbines, compressors, fans, centrifuges and other turbo machinery.
Parameters:
Model Number:MMS6410
Number of Inputs: Two independent
Type: Differential, galvanically isolated
Protection: Open circuit and short circuit proof
Max.Input Voltage: 3.6 V
Nominal Input Voltage Range: 2.5 V rms
Input lmpedance: 200 kQ
Pulse per Revolution: 1
Logic: 24 V
Input Resistance: > 30 kQ
Pulse Duration: Minimum 10 μs
Features:
-For connection of inductive displacement sensors for measuring absolute expansion, e.g., epro sensors PR 9350/.
-Signal frequency range up to 100 Hz.
-Zero adjustment and zero shift independently from the chosen measuring range.
-Measuring results of both channels can be combined with each other, e.g., for the calculation of sum and difference values.
-Sensor supply balanced to ground to suppress disturbances in industrial environments.
-RS 232 interface for configuration and reading out measuring results.
-RS 485 interface for connection to epro's MMS 6800 analysis and diagnosis system or to host computers.
