Manufacture |
Bently Nevada |
|
Model |
330196-05-30-50-05 |
| PN No. |
330196-05-30-50-05 |
|
Catalog |
3300XL |
|
Description |
ETR Proximity Probes |
| Origin | U.S.A. |
| HS CODE |
85389091 |
| Dimension |
24*2.4*16 (CM) |
| Weight | 0.5 kg |
Description:
330195: Base model for the 3300 XL 8 mm ETR Probe (with 3/8-24 UNF threads and Reverse Mount Probes).
-05: Unthreaded Length Option. Specifies an unthreaded body portion of 50 mm.
-30: Overall Case Length Option. Indicates a total threaded/unthreaded case length of 300 mm.
-50: Total Length Option. Designates a total probe cable length of 5.0 meters (16.4 feet).
-05: Agency Approval Option. Configured with Multiple Approvals (including CSA, ATEX, and IECEx) for safe use in globally recognized hazardous areas.
Technical Specifications & Compatibility
System Pairing: Specifically designed to work within a 3300 XL 8mm Proximity Transducer System. It bridges a 9.0-meter probe and a 5.0-meter Proximitor Sensor to achieve a standard 5-meter total system calibration.
Physical Protection: The rugged stainless steel armor shields the sensitive coaxial core from physical crushing, sharp bends, and abrasive friction in harsh industrial areas.
Locking Mechanism: Utilizes standard miniature coaxial connectors featuring a patented ClickLoc connection design to prevent the cable joints from vibrating loose.
RELATED PRODUCTS
| 330190-040-00-RU |
| 330190-040-00-00 |
| 330190-040-01-00 |
| 330190-085-00-05 |
| 330190-080-01-05 |
| 330190-080-00-00 |
| 330190-045-00-00 |
| 330190-075-01-CN |
| 330190-080-01-00 |
| 330191-00-33-90-05 |
| 330191-00-30-05-02-00 |
| 330191-00-16-10-05 |
| 330191-00-40-90-02-00 |
| 330191-00-08-90-05 |
| 330191-00-33-90-CN |
| 330191-00-33-90-05 |
| 330192-10-80-90-05 |
| 330192-00-60-20-05 |
| 330192-00-11-10-05 |
| 330193-00-04-10-00 |
| 330193-00-04-10-00 |
| 330193-00-02-50-00 |
| 330194-03-06-10-CN |
| 330194-13-20-10-00 |
| 330194-13-19-10-00 |
| 330194-03-06-10-05 |
| 330194-00-07-10-05 |
| 330194-05-13-10-05 |
| 330194-05-13-50-05 |
| 330194-15-25-50-05 |
| 330195-02-12-90-CN |
| 330195-02-12-90-05 |
Frequently Asked Questions:
1.What is the 330196-05-30-50-05 Temperature Range?
An extended temperature range (ETR) probe and ETR extension cable are available for applications in which either the probe lead or extension cable may exceed the standard 177˚C (350˚F) temperature specification. The ETR probe has an extended temperature rating for up to 218˚C (425˚F). The ETR extension cable rating is up to 260˚C (500˚F). Both the ETR probe and cable are compatible with standard temperature probes and cables, for example, you can utilize an ETR probe with the 330130 extension cable. The ETR system uses the standard 3300 XL Proximitor Sensor. Note that when you use any ETR component as part of your system, the ETR component limits the system accuracy to the accuracy of the ETR system.
2.What is the payment term?
Only wire transfer
3.When does the warranty period start?
One year from the time the client receives the goods.
Datasheet Link:
330196-05-30-50-05 Bently Nevada, 3300XL ETR Proximity Probes PDF Datasheet
