EZ1901-080 EPRO 8mm Eddy Current Sensor

Description:
The Emerson EZ1901-080 is a compact eddy current displacement sensor designed for precise vibration and shaft position monitoring in turbomachinery such as turbines, compressors, pumps, and fans. Its reverse-mount configuration with M10 × 1 thread size allows easy installation in confined spaces. With an 8 mm sensor diameter and robust IP67 protection, it ensures reliable operation even in harsh industrial conditions.

Specifications:
Model: EZ1901-080

Sensor Diameter: 8 mm
Mounting Configuration: Reverse mount
Thread Size: M10 × 1
Cable Length: 1.0 meter
Linear Measurement Range: 2 mm (80 mils)
Initial Air Gap: 0.5 mm (20 mils)
Incremental Scale Factor (ISF) API : 7.87 V/mm ±5%; ISO: 8 V/mm ±5%
Straightness Deviation (DSL): ±0.025 mm (±1 mil)
Minimum Target Size : 14 mm (recommended ≥20 mm)
Minimum Shaft Diameter : 20 mm (recommended ≥25 mm)
Target Material Compatibility :  Ferromagnetic steels
Operating Temperature (Sensor): –35°C to +180°C
Operating Temperature (Cable): –35°C to +150°C
Protection Rating : IP67
Rated Pressure: 10,000 hPa

Features:

• Non-Contact Measurement

ldeal for shaft vibration, displacement, and gap detection

• Compact Design

Small footprint for tight installation spaces

• High Reliability

Designed for long-term use in harsh industrial conditions

• Flexible Integration

Compatible with AMS monitoring systems and extension cables

• Customizable Options

Available in various thread sizes, cable lengths, and configurations

Frequently Asked Questions:

1.What is the payment term?
Wire transfer only.

2.When does the warranty period start?
One year from the time the client receives the goods.

Datasheet Link:

EZ1901-080 8mm Eddy Current Sensor PDF Datasheet
