IS200ISBEH2ABC GE ISbus Extender Board Connector

Description:

The IS200ISBEH2ABC is a PCB assembly manufactured by General Electric (GE) for the Mark VI system. Mark VI is one of the last products in GE's Speedtronic gas or steam turbine management series. Mark VI includes Ethernet communication and a Human-Machine Interface (HMI), which consists of a PC running a Windows operating system. The HMI allows users to access data within the system, but it is not a necessary component. The IS200ISBEH2ABC InSync bus expansion card is an important part of the Mark VI turbine control system series.

Parameters:
Part Name: IS200ISBEH2A
Manufacturer: GE
Board Series: Mark VI
Designation: ISBus Expansion Board
Revision: A
Functional Acronym: ISBE
Group: 2
Full Revision: ABC
Features:

• Ethernet 1-Port Communication

This is an embedded Ethernet interface module used for network communication.

• Digital Input

As a general-purpose digital input module, it can receive digital signals from external devices and transmit these signals to the control system.

• Analog Output

This module also features analog voltage or current output capabilities. It can output corresponding analog signals according to the control system's commands, thereby driving external devices or controlling actuators.

Frequently Asked Questions about IS200ISBBG1AAB:

1.Which Mark VI Series revisions does this IS200ISBEH2ABC InSync Bus Extender Card device utilize?
This IS200ISBEH2ABC InSync Bus Extender Card PCB is edited through two funcctional revisions and an artwork configuration revision rated at grades of A, B, and C, in respect.

2.What is a potential cause of this IS200ISBEH2ABC InSync Bus Extender Card device's group 2 Mark VI Series grouping?
While unconformable, it is likely that this IS200ISBEH2ABC InSync Bus Extender Card device's relatively small base PCB size is the root cause of its uncommon group 2 Mark VI Series grouping.

3.What type of assembly is the IS200ISBEH2A?
The IS200ISBEH2A is a standard PCBA.

4.What do the revisions mean on the IS200ISBEH2A?
The revisions are for hardware form, functional revision, and artwork revision.

5.Is there stock available or how long is the lead time?

Lead time: In stock

Datasheet Link:

IS200ISBEH2ABC GE ISbus Extender Board Connector PDF Datasheet
