IS200SRLYS2A GE MKVI, Relay Terminal Board, Simplex

Description:

IS200SRLYS2A is a Simplex Relay Output Terminal Board manufactured and designed by General Electric as part of the Mark VI Series used in GE Speedtronic Gas Control System.

Control Modules
UCCC - executes configured logic for a safety instrumented function (SIF) based on the currentprocess inputs to control the process outputs.
UCSB - executes configured logic for a safety instrumented function (SIF) based on the currentprocess inputs to control the process outputs.
Typical Process I/O
Typical process inputs include contact, analog, and thermocouple signals. Typical process outputsinclude relays and analog outputs. All outputs based on inputs for typical process I/O requireprocessing by the system controller.
BPPB - Common l/O processor board which is used for all l/O types. This board is combined withan I/O type specific data acquisition board in order to create a specific type of I/O module

YAIC- Ten analog inputs (voltage, 4-20mA) and two 4-20mA analog outputs. Single and triple pack capable.
YHRA- Ten 4-20mA analog inputs, two 4-20mA analog outputs, all HART enabled. Capable of onlysingle pack operation with one or two networks
YDIA- Twenty-four contact closure inputs with group isolation. Available nominal voltage rangesinclude 24V, 48V, and 125V dc. Capable of single, dual, or triple pack operation on an appropriateterminal board.
YDOA- Twelve relay outputs with feedback determined by the associated terminal board. Capableof single and triple pack operation.
YTCC- Twelve thermocouple inputs. Capable of single, dual, or triple pack operation on anappropriate terminal board.
YVIB - Twelve vibration inputs. Provides a direct interface to seismic (velocity), proximity,velomitor and accelerometer type probes. Capable of single and triple pack operation.

Frequently Asked Questions:

1.What is a simplex relay output terminal board?

Asmplex relay output terminal board is a device used i industral control ystems to contrel electricalloads. contains multiple relys that ac as swtchesto tu connecteddevices on or off based on external control signals.

What are the main applications of simplex relay output terminal boards?
These boards are commonly used in industrial automaton, process control,manufacturing, and buiding automation systems to controlmotors, lght, solenoids, pumps, and
other electrical loads.
