140CRP93200 Schneider Electric RI0 Head-end Adaptor Module

140CRP93200 Schneider Electric RI0 Head-end Adaptor Module in stock.

Item NO.:
140CRP93200
Payment:
T/T
Market Price:
$143
Product Origin:
France
Color:
Depends on material
Shipping Port:
Xiamen
Lead Time:
5-7 days
Goods Stock:
99
Product weight:
0.91 kg

Inquiry now

product introduction

Manufacture	Schneider
Model	140CRP93200
PN No.	140CRP93200
Catalog	Modicon Quantum
Description	Ethernet network TCP/IP module
Origin	U.S.A.
HS CODE	85389081
Dimension	516.531.5(CM)
Weight	0.91kg

Description:

The 140CRp93200 is an essential module within the Modicon Quantum automation platform, designed to facilitatecommunication between the central processing unit (CPU) and remote l/0 devices. This Rl0 head-end adaptormodule enables distributed l/0, offering increased system flexibility, scalability, and high-speed communication forindustrial applications. lt is highly reliable, with built-in redundancy to ensure continuous operation and preventsystem downtime.

Specifications:
Product Name: 140CRP93200

Maximum Drops/Network: 31
l/0 Words/Drop: 64 l/0 input and 64 l/0 output
Cable Type: 75 0hm coaxial cable
Transmission Rate: 1544 Mbit/s
Dynamic Range: 35 dB
Isolation Voltage: 500 V DC between coaxial center and ground
Power Dissipation: 3 W (2 channels)
Bus Current Requirement: 750 mA (2 channels)
Ambient air temperature for operation: 32…140 °F (0…60 °C)
Ambient Air Temperature for Storage:-40…185 °F (-40…85 °C)
Relative Humidity: 95 % without condensation
Operating altitude: <= 16404.2 ft (5000 m)

Feartures:

Profibus Communication function

Schneider 140CRP81100, as a Profibus interface module, can provide an efficient means of data communication between master and slave stations. The Profibus link not only connects various devices to the Schneider Quantum series PLC system but also enables centralized control and monitoring of different devices for uniform production process management.
