Bently Nevada 3500 Series Online Monitoring and Protection System. This monitoring and protection system provides continuous online condition monitoring and protection for your equipment. The Bently 3500 system is compatible with Bently vibration sensor probes and accepts Bently proximity eddy current sensors, velocity and acceleration sensors (such as the 330400 and 330500), and various composite sensors. It is a world leader in detecting and preventing false trips and erroneous trips in rotating machinery. With over 80,000 units installed worldwide, it provides automatic protection values by monitoring machines for trips, preventing costly damage when needed. The 3500 system also protects your machines and processes from false trips that can cause unwarranted downtime, resulting in costly downtime or production losses. When connected to System 1* software, it also provides continuous condition monitoring information for proactive maintenance planning. The 3500 system combines the industry's broadest selection of mechanical measurement parameters with software configurations for virtually any mechanical monitoring scenario. The 3500 system fully complies with the American Petroleum Institute (API) 670 standard for this type of system. It is the most powerful and flexible system in Bentley Nevada's traditional framework system, possessing numerous features and advanced functions not found in other systems.

Key features: Self-monitoring and fault-tolerant design; configurable with multiple redundancy options, ranging from adding a second fully redundant power supply to a complete triple modular redundancy (TMR) configuration; usable on selected or all channels; fully meeting the needs of the most mission-critical applications; seamlessly integrates with Bentley's System1 condition monitoring and diagnostic analysis software platform; communicates with plant control and automation systems via a communication gateway module; designed to comply with API 670; designed to comply with API 618 for reciprocating compressor applications; DNV and Class NK certifications for offshore applications; certified by the Canadian Standards Association (CSA), Factory Cooperation (FM), GOST, ATEX, and CE.

The Bentley 3500 vibration monitoring and protection system provides online monitoring capabilities.

The Bently 3500 system can monitor the vibration of large rotating machinery, including steam turbines, water turbines, fans, compressors, turboexpanders, electric motors and generators, exciters, gearboxes, and water pumps.

The Bently 3500 series mechanical protection system, with its monitor and Bently Nevada vibration sensor probes, offers a wide measurement range and works well with Bently Nevada vibration monitoring products. It can be used to measure shaft vibration, shaft displacement, key phase, speed, overspeed protection, eccentricity, thermal expansion, differential expansion, etc., and accepts vibration signals from the Bently 3300 eddy current sensor system (Bently 3300XL sensor probe, extension cable, preamplifier) as well as speed and acceleration sensors such as 330500, 330400, and 9200. It meets the American Petroleum Institute 670 standard. The Bently 3500 system can monitor the vibration of large rotating machinery: steam turbines, water turbines, fans, compressors, turboexpanders, electric motors and generators, exciters, gearboxes, water pumps, etc. It is widely used in power plants, chemical plants, oil refineries, steel mills, machinery factories, pump factories, fan factories, universities and research institutions, and automation instrumentation companies. The Bently 3500 frame instrumentation system mainly includes:

Bently 3500/05 System Rack: Model 14 module slots 3500/05-01-01-00-00-01; 7 slots 3500/05-02-04-00-00-01

Bently 3500/15 Power Supply (New): Model 3500/15-05-05-00 (Front panel 106M1079-01, Rear panel 106M1081-01)

Bently 3500/20 Rack Interface Module

Bently 3500/22M Transient Data Interface Module with TDI: Model 3500/22-01-01-00 (Front panel 288055-01, Rear panel 146031-01)

Bently 3500/25 Key Phaser ModuleEnhanced Keyphasor Module Model 3500/25-01-01-00 (Front panel 149369-01, Rear panel 125800-01)

Bently 3500/32 4-channel relay module: Model 3500/32-01-00 (Front panel 149986-02, Rear panel 125720-01)

Bently 3500/33 16-channel relay module: Model 3500/33-01-00 (Front panel 149986-01, Rear panel 149992-01)

Bently 3500/34 TMR relay module

Bently 3500/40M Proximitor Monitor: Model 3500/40-01-00 (Front Panel 176449-01, Rear Panel 125680-01)

bently 3500/42M Proximitor Seismic Monitor: Model 3500/42-01-00 (Front Panel 176449-02, Rear Panel 128229-01)

bently 3500/44M Aeroderivitive GT Vibration Monitor

bently 3500/45 Position Monitor: Model 3500/45-01-00 (Front Panel 176449-04, Rear Panel 135137-01)

bently 3500/46M Hydroelectric Monitor

bently 3500/50 Speed ModuleTachometer Module: Model 3500/50-01-00-01 (Front Panel 288062-02, Rear Panel 133442-01)

Bently 3500/53 Overspeed Detection Module

Bently 3500/60 and 3500/61 Temperature Monitors: Model 3500/60-01-00 (Front Panel 163179-01, Rear Panel 133819-01); 3500/61-01-00 (163179-02, 133819-02)

Bently 3500/62 Process Variable Monitor: Model 3500/65-01-00 (Front Panel 14598802, Rear Panel 17210301)

Bently 3500/64M Dynamic Pressure Monitor

Bently 3500/72M Recip Rod Position Monitor

Bently 3500/77M Recip Cylinder Pressure Monitor

Bently 3500/90 Communication Gateway

Bently 3500/92 Communication Gateway: Models 3500/92-04-01-00 (136180-01, 136188-02) and 3500/92-02-01-00 (136180-01, 133323-01)

Bently 3500/01-01 Configuration Software

Bently 3500/06 Protective Housing

Bently 3500/08 Fault Diagnosis Connection Panel

Bently 3500 Internal safety barrier: Model 3500/04 (136719-01, 138257-01)

Bently 3500/93 Standalone Display

Bently 3500/93 LCD Display Device

Bently 3500/94 VGA Display Device

Bently 3500/95 User Interface Workstation
