3. 3500/20 Frame Interface Module: The Frame Interface Module (RIM) is the basic interface for the 3500 frame. It supports Bentley Nevada's proprietary protocols for frame configuration and retrieving information from the unit. The Frame Interface Module must be placed in the first slot of the frame (closest to the power supply). The RIM can connect to compatible Bentley Nevada communication proce...

12.3500/92 Communication Gateway The 3500/92 Communication Gateway module provides extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities. It also permits Ethernet communications with 3500 Rack Configuration Software and Dat...

In the majority of supercritical and subcritical units at turbine manufacturing plants, relative vibration measurements are utilized for unit protection. The standard protection strategy employs a set of orthogonal shaft vibration probes mounted on a single bearing; a protective shutdown is triggered whenever the reading from any one of these probes reaches the designated trip value. However, an i...

Bently Nevada machinery protection and monitoring systems span more than a dozen different models deployed during the last 60 years. Combined, they comprise the largest installed base of permanently installed transducers and monitoring channels in the world. It’s a position of trust that has been earned over more than six decades of learning, refining, and improving our solutions to meet the indus...
